United Steel Products 9-1/2" FACE MOUNT HANGER

Provides full lateral support of the I-joist top chord. Web stiffeners are normally not required when the hangers side flanges support the top flange of the I-joist. Raised dimple ensures proper 45 nailing. Seat cleat automatically holds the I-joist bottom flange tight to the hanger seat. +----------|-----------------|----------------------|--------------------|-------------------------|-------------|--------------|---------------+ | Number | Trus JoistSizes | Georgia PacificSizes | Boise CascadeSizes | Louisiana Pacific Sizes | HangerWidth | HangerHeight | HangerDepth | +----------|-----------------|----------------------|--------------------|-------------------------|-------------|--------------|---------------+ | THF15925 | 9-1/2" TJI15 | 9-1/2" GPI15 | | 9-1/2" LPI26 | 1-9/16" | 9-1/4" | 2" | | THF17112 | 11-7/8" TJI25 | 11-7/8" GPI25 | 11-7/8" BCI45 | 11-7/8" LPI30 | 1-13/16" | 11-1/8" | 2" | +----------|-----------------|----------------------|--------------------|-------------------------|-------------|--------------|---------------+
