United Steel Products 2X4 JOIST HANGER

Light gauge face mount joist hangers to accommodate application and installation preferences. JL series: 20-gauge, 2x joist hangers. JR series: 18-gauge, 2x hangers. JE series: 18-gauge 2x joist hangers, full 2" seat. G90 galvanizing. +------------------|----------|--------|-------|-------|---------+ | Joist Size | Mfg. No. Dimensions | +------------------|----------|--------|-------|-------|---------+ | | W | H | D | A | | 2 x 4 | JL24 | 1-9/16 | 3 | 1-1/2 | 15/16 | | 2 x 6 8 | JL26 | 1-9/16 | 4-3/4 | 1-1/2 | 15/16 | | 2 x 8 10 | JL28 | 1-9/16 | 6-3/8 | 1-1/2 | 15/16 | | 2 x 10 12 14 | JL210 | 1-9/16 | 8-1/4 | 1-1/2 | 15/16 | | 2 x 4 | JRSSS | 1-9/16 | 3 | 1-1/2 | 15/16 | | 2 x 6 8 | JRSS | 1-9/16 | 4-3/4 | 1-1/2 | 15/16 | | 2 x 8 10 | JRS | 1-9/16 | 6-3/8 | 1-1/2 | 15/16 | | 2 x 10 12 14 | JRSX | 1-9/16 | 8-1/4 | 1-1/2 | 15/16 | +------------------|----------|--------|-------|-------|---------+
